Product Description
The XM Series 4-Channel Marine Amplifier delivers powerful, high-efficiency performance built for marine and extreme installations. Engineered with coated 5-layer epoxy circuit boards, stainless steel components, and advanced aluminum heat sinks, this amp is rugged, reliable, and designed for maximum heat dissipation. With 225W x 4 at 2Ω and 450W x 2 bridged at 4Ω, it provides clean, powerful sound for any setup. Every unit is CEA-2006 compliant and bench-tested at the time of manufacture, ensuring verified, high-performance output you can trust.
Key Features:
✔ 4-Channel Class-D Design – Delivers high power with maximum efficiency
✔ 225W x 4 at 2Ω / 450W x 2 Bridged at 4Ω – Versatile, high-output performance
✔ Coated 5-Layer Epoxy Circuit Boards – Marine-grade durability
✔ 9.8g Aluminum Heat Sinks – Exceptional heat dissipation
✔ CEA-2006 Compliant & Bench-Tested – Verified, consistent performance
✔ Low-Pass & Subsonic Crossovers (50-250Hz & 15-250Hz) – Precision tuning
✔ Bass Boost (0 to +18dB @ 45Hz) – Enhanced low-end response
✔ Remote Bass Control Included – Adjust bass levels on the fly
Power Ratings:
🔹 4Ω: 150W x 4
🔹 2Ω: 225W x 4
🔹 Bridged 4Ω: 450W x 2
Specifications:
📡 Frequency Response: 30 – 200Hz
🎚 Gain Range: 0.2 – 6V
🎛 Total Harmonic Distortion: <0.5%
🔊 Signal-to-Noise Ratio: 92dB
⚡ Fuse Size: 40A x 3
🔌 Recommended Wire Gauge: 4 AWG
Dimensions:
📏 Length: 12.7 in (322.6mm)
📏 Width: 7.5 in (190.5mm)
📏 Height: 2.3 in (58.4mm)
